Description:| Specification Type | Values |
|---|---|
| • CAPACITY | |
| Cooling (Min ~ Rated ~ Max) | 5.28 kW |
| 18,000 Btu/h | |
| 18,990 kJ/h | |
| • POWER INPUT | |
| Cooling (Min ~ Rated ~ Max) | 1,540 W |
| • RUNNING CURRENT | |
| Cooling (Min ~ Rated ~ Max) | 7.10 A |
| • EER | |
| EER | 3.43 W/W |
| 11.69 (Btu/h)/W | |
| 12.33 (kJ/h)/W | |
| • POWER SUPPLY | |
| Power Supply | 1, 230, 60 (Ø, V, Hz) |
| Available Voltage Range | 187 ~ 276 V |
| Power Factor - Cooling | 94% |
| Moisture Removal | 1.25 l/h |
| 2.64 pts/h | |
| Circuit Breaker | 25 A |
| Power Supply Cable | 3 × 1.5 No. × mm² |
| Power Supply to Unit | Indoor |
| Power and Communication Cable | 4 × 1.5 No. × mm² |
| • INDOOR UNIT | |
| Air Flow Rate - Cooling, Max/H/M/L | 18/12.7/10.2/8.4 m³/min |
| 635.7/448.5/360.2/296.6 CFM | |
| Fan Motor Speed - Cooling, Max/H/HM/M/ML/L/SL | 1500/1150/1050/950/860/770/700 rpm |
| Sound Pressure Level - Cooling, Max/H/M/L/SL | -/45/40/37/32 dB(A) |
| Dimensions (W × H × D) - Net | 998 x 345 x 210 mm |
| Dimensions (W × H × D) - Shipping | 1068 x 425 x 279 mm |
| Weight - Net | 11.2kg |
| Weight - Shipping | 13.2kg |
| Disconnect Switch | 25 A |
| Exterior Color Code | Munsell 7.5BG 10/2 (RAL 9016) |
| Operation Range - Cooling | 16 ~ 32 °C DB |
| 61 ~ 90 °F DB | |
| 10 ~ 23 °C WB | |
| 50 ~ 73.4 °F WB | |
| • OUTDOOR UNIT | |
| Air Flow Rate - Max | 31.0 m³/min |
| 1095 CFM | |
| Sound Pressure Level - Cooling, Rated | 53 dB(A) |
| Dimensions (W × H × D) - Net | 770 x 545 x 288 mm |
| Dimensions (W × H × D) - Shipping | 920 x 588 x 393 mm |
| Weight - Net | 32.5kg |
| Weight - Shipping | 34.8kg |
| Max. Fuse Size | 15 A |
| Exterior Color Code | Munsell 9.54Y 8.34/1.31 (RAL 9001) |
| Operation Range - Cooling | 18 ~ 48 °C DB |
| • PIPING | |
| Size - Liquid | ø 6.35 mm |
| Size - Gas | ø 12.7 mm |
| Connections Method - Indoor/Outdoor | Flared/Flared |
| Drain Hose Size - O.D, I.D | 21.5, 16.0 mm |
| Max Piping Length Capacity | 98.7% |
| • REFRIGERANT | |
| Type | R32 |
| Pre Charge | 950g |
| Additional Charge | 15g/m |
| Control | Capillary |
| Global Warning Potential | 675 |
| t-CO₂ eq | 0.641 |
| • COMPRESSOR | |
| Type | Twin Rotary |
| Model | DAT156MAD |
| Motor Type | BLDC |
| Oil Type / Maker | PVE (FW68D) / IDEMITSU |
| Oil Charge | 400cc |
| Manufacturer / Country of Origin | LG Electronics / China |
| • HEAT EXCHANGER | |
| Evaporator - Material, Tube / Fin | Cu/Al |
| Evaporator - (ø x Row x Column x FPI x L) x Qty. | (ø7 x 2 x 16 x 20 x 744) x 1 |
| Evaporator - Corrosion Protection | PCM |
| Evaporator - Fin Type | Slit |
| Condenser - Material, Tube / Fin | Cu/Al |
| Condenser - (ø x Row x Column x FPI x L) x Qty. | (ø7 x 2 x 24 x 18 x 823) x 1 |
| Condenser - Corrosion Protection | Gold |
| Condenser - Fin Type | Louver |
