₱ 68,888.00
As low as ₱ 5,125.00/mo
Out of Stock
Ordering Unit: pc
Description:| Specification Type | Values |
|---|---|
| • CAPACITY | |
| Cooling (Min ~ Rated ~ Max) | 6.30 kW |
| 21,500 Btu/h | |
| 22,683 kJ/h | |
| • POWER INPUT | |
| Cooling (Min ~ Rated ~ Max) | 1,850 W |
| • RUNNING CURRENT | |
| Cooling (Min ~ Rated ~ Max) | 8.50 A |
| • EER | |
| EER | 3.41 W/W |
| 11.62 (Btu/h)/W | |
| 12.26 (kJ/h)/W | |
| • POWER SUPPLY | |
| Power Supply | 1, 230, 60 (Ø, V, Hz) |
| Available Voltage Range | 187 ~ 276 V |
| Power Factor - Cooling | 97.2% |
| Moisture Removal | 2.80 l/h |
| 5.92 pts/h | |
| Circuit Breaker | 30 A |
| Power Supply Cable | 3 × 1.5 No. × mm² |
| Power Supply to Unit | Indoor |
| Power and Communication Cable | 4 × 1.5 No. × mm² |
| • INDOOR UNIT | |
| Air Flow Rate - Cooling, Max/H/M/L | 20/15/12.5/10.6 m³/min |
| 706/530/441.5/374 CFM | |
| Fan Motor Speed - Cooling, Max/H/HM/M/ML/L/SL | 1600/1200/1100/1000/920/850/700 rpm |
| Sound Pressure Level - Cooling, Max/H/M/L/SL | -/47/41/37/32 dB(A) |
| Dimensions (W × H × D) - Net | 998 x 345 x 210 mm |
| Dimensions (W × H × D) - Shipping | 1068 x 425 x 279 mm |
| Weight - Net | 11.6kg |
| Weight - Shipping | 13.4kg |
| Disconnect Switch | 30 A |
| Exterior Color Code | Munsell 7.5BG 10/2 (RAL 9016) |
| Operation Range - Cooling | 16 ~ 32 °C DB |
| 61 ~ 90 °F DB | |
| 10 ~ 23 °C WB | |
| 50 ~ 73.4 °F WB | |
| • OUTDOOR UNIT | |
| Air Flow Rate - Max | 49.0 m³/min |
| 1730 CFM | |
| Sound Pressure Level - Cooling, Rated | 55 dB(A) |
| Dimensions (W × H × D) - Net | 870 x 650 x 330 mm |
| Dimensions (W × H × D) - Shipping | 1040 x 710 x 455 mm |
| Weight - Net | 42.5kg |
| Weight - Shipping | 45.9kg |
| Max. Fuse Size | 20A |
| Exterior Color Code | Munsell 9.54Y 8.34/1.31 (RAL 9001) |
| Operation Range - Cooling | 18 ~ 48 °C DB |
| • PIPING | |
| Size - Liquid | ø 6.35 mm |
| Size - Gas | ø 15.88 mm |
| Connections Method - Indoor/Outdoor | Flared/Flared |
| Drain Hose Size - O.D, I.D | 21.5, 16.0 mm |
| Max Piping Length Capacity | 94.8% |
| • REFRIGERANT | |
| Type | R32 |
| Pre Charge | 1150g |
| Additional Charge | 20g/m |
| Control | Electronic Expansion Valve |
| Global Warning Potential | 675 |
| t-CO₂ eq | 0.776 |
| • COMPRESSOR | |
| Type | Twin Rotary |
| Model | DAT156MAD |
| Motor Type | BLDC |
| Oil Type / Maker | PVE (FW68D) / IDEMITSU |
| Oil Charge | 400cc |
| Manufacturer / Country of Origin | LG Electronics / China |
