Specification Type

Values




Series:



Clean Cool Pro




Cooling Capacity:



32400（5000-36000）




Power Input (W):



2650（500-3300）




EER (KJ/wh):



12.2264150943




CSPF:



5




DOE Star level:



5 star




Running Current (A):



11.8




Air Circulation (m3/h):



1300




Moisture Removal (10-3m3/h):



3




Refrigerant Type:



R32













Indoor Unit








Indooor Unit Net Dimension (mm) W/D/H:



1316*270*365




Indooor Unit Package Dimensin (mm) W/D/H:



1418*478*391




Indooor Unit Net Weight (kg):



21.5




Indooor Unit Gross Weight (kg):



25.5




Noise (dB) (Hi/Mid/Lo/Sleep):



51/45*40/33













Outdoor Unit








Net Dimension (mm) W/D/H:



950/370/815




Package Dimensin (mm) W/D/H:



1090/475/887




Net Weight (kg):



51




Gross Weight (kg):



56




Noise (dB):



54













Pipe








Refrigerant pipe (mm) Liquid side diameter (mm):



6.35




Refrigerant pipe (mm) Gas side diameter (mm):



15.88




Maximum Pipe Length (m):



25




Maximum Elevation Length (m):



15




Chargeless Pipe Length (m):



5




Amount of Gas (g):



1550




Add'l Charge of Refrigerant (g):



20




Power Supply:



outdoor
